Details
| Sanding width （max） | 1300 mm |
| Sanding thickness | 5-150 mm |
| Sanding length | >500 mm |
| Abrasive belt speed (First) | 20m/s |
| Abrasive belt speed (Second) | 22m/s |
| Abrasive belt dimension | 1350×2700 mm |
| Total capacit of motors | 113.25 kW |
| Motor for sanding head （First） | 55 kW |
| Motor for sanding head （Second） | 45 kW |
| Motor for feed | 11 kW |
| Motor for lifting | 0.75 kW |
| Motor for brush | 0.75 kw×2 |
| Feed speed | 10-30m/min |
| Power | 380V 50Hz |
| Operating pressure | 0.6-0.8Mpa |
| Capacity of suction extraction | 24000m3/h |
| Dimensions[L×W×H] | 3800×3000×2530 mm |
| Net mass | 23000kg |
