Details：
| Sanding width （max） | 40-1300 mm |
| Sanding thickness | 2.5-110 mm |
| Sanding length | >780 mm |
| Abrasive belt speed | 20m/s 24m/s |
| Abrasive belt dimension | 1330×2620 mm |
| Voltage | 380AV |
| Frequency | 50Hz |
| Total capacit of motors | 57.5 kW |
| Motor for sanding head | 30kW 18.5kW |
| Motor for feed | 7.5 kW |
| Motor for lifting | 0.75 kW |
| Motor for brush | 0.75 kw |
| Feed speed | 20-50m/min 50-80m/min |
| Operating pressure | 0.6-0.8Mpa |
| Capacity of suction extraction | 7900m3/h |
| Dimensions[L×W×H] | 2400×2770×2440 mm |
| Net Mass | 8500kg |
