Details：
| Sanding width （max） | 1300 mm |
| Sanding thickness | 5-150 mm |
| Sanding length | >750 mm |
| Abrasive belt speed (First) | 25 m/s |
| Abrasive belt speed (Second) | 18.5 m/s |
| Abrasive belt dimension | 1350×2800 mm |
| Total capacit of motors | 283.49 kW |
| Motor for sanding head | 75 kW×2 55 kW×2 |
| Motor for feed | 22 kW |
| Motor for lifting | 0.75 kW |
| Motor for brush | 0.37 kW×2 |
| Power supply | 308V 50Hz |
| Feed speed | 10-30 m/min |
| Operating pressure | 0.6-0.8 MPa |
| Capacity of suction extraction | 32000m3/h |
| Dimensions[L×W×H] | 3000×3100×3050 mm |
| Net weight | 16000kg |
